DW 5002TD4 Turbo Double Bass Drum Pedal with Case
The 5002TD4 is a double bass drum pedal whose cam keeps the same ratio from the first millimetre to the last: whatever the footboard travels, the beater follows, always in the same proportion. On a double pedal, that consistency is worth even more than on a single, because your left foot then has one feel to learn, not two.
What sets it apart
- Turbo cam, constant ratio through the whole stroke, on both sides
- Double chain on a sprocket, for stability under load
- Aluminum hex shafts, aluminum footboards and linkage parts
- Spring rocker with two bearings
- Toe clamp with three swivelling rubber pads
- Ballistic nylon carrying case with a hard lining
Your weaker foot has nothing extra to learn on a double
An offset cam speeds the beater up at the end of the stroke. The right foot, which works every day, learns that acceleration and uses it. The left foot, meanwhile, is discovering the motion, the lag of the linkage and that surge of speed all at once. Three unknowns at the same time.
With a Turbo cam, the third one disappears. The ratio between what the footboard travels and what the beater travels never changes: the left foot only has to learn where to sit and how much to give. Many drummers who could not even out their two feet find out that this was where the problem came from.
Why hex shafts rather than round ones
A round shaft transmits its motion through a screw tightened on its smooth surface. Under repeated strokes, that screw ends up marking the metal, then turning in the mark it has dug: the shaft slips a degree or two, and the left side falls behind without warning.
A hex profile cannot turn in its housing: the shape itself carries the torque, and the screw only holds the shaft in place. It is a difference you cannot see in a store and that you measure after three years of gigs.
A hard-lined case, and what it really protects
Ballistic nylon resists the abrasion of floors and loading. The hard lining protects something else: your settings. A double pedal thrown into a soft bin takes knocks on its stroke and spring screws, and a setup found after months of trial and error is lost in a single night.
Every part — the two halves, the shaft, the beaters — has its place. Setting up the next day stops being a rebuild.
Specifications
| Type | Double bass drum pedal |
|---|---|
| Cam | Turbo, constant ratio |
| Drive | Double chain |
| Shafts | Hex, aluminum |
| Spring rocker | Two bearings |
| Transport | Ballistic nylon case with a hard lining |
What it is for
- Drummers struggling to even out their two feet
- Music where control matters more than top speed
- Jazz, soul and band music with fine dynamics
- Touring, with daily setup and teardown
- Moving from an entry-level double pedal to stage gear
Compare with other manufacturers
Double pedals with a concentric cam from other manufacturers:
| Manufacturer | Comparable model | What differs |
|---|---|---|
| Tama | Speed Cobra 910 double | Long cam and longboard as standard |
| Pearl | Eliminator Solo double | Round cam interchangeable with other profiles |
| Yamaha | DFP9500C double | Cam with two profiles selected by flipping the part |
| Gibraltar | 6711 series double pedal | Single chain as standard, assembled construction |
Frequently asked questions
- What is the difference from the Accelerator version of the same pedal?
- The cam. Turbo keeps a constant ratio; Accelerator makes the beater gain speed at the end of the stroke. The rest of the mechanism is the same.
- Is a Turbo cam slower?
- No. Its speed depends entirely on your foot rather than on the geometry. What drummers used to an offset cam feel at first is the absence of a whip effect, not a lack of power.
- Is the case really included?
- Yes. The manufacturer lists a deluxe ballistic nylon carrying case with a hard lining with this double pedal.
- Can I play it as a single pedal?
- The main pedal works on its own. The linkage and the auxiliary footboard come off when you do not need them.
